Note (1) The specification torque is the data when the temperature is 23±2℃. Note (2) Special torque customization can be provided by changing the viscosity of the buffer viscous oil;
1. When the N36A0 series rotary buffer starts to fall from the vertical position shown in Figure A to the horizontal position, since the designed torque is the weakest at the starting position, with the rotation of the buffer angle, the torque gradually increases, so the action of the cover can be Finally close slowly. As shown in Figure B, when the lid starts to fall from the horizontal position, the torque generated by the gravity of the lid is zero in the vertical direction, and the torque of the buffer is the largest in the final position, so the lid cannot be completely closed
Note 1) The marked torque is the data measured when the standard load rotates 15° per second and the temperature is 23°C: Note 2) Turn over to change the installation positioning surface, so that the damping output buffers the torque in a clockwise direction; Note 3) Special torque customization can be provided by changing the viscosity of the shock absorber viscous oil.
